詳細信息
輪式多功能液壓攪拌機產品廣泛適用于建筑工程、市政工程、公立、橋梁、城鄉道路、預制廠、小型預制構件廠等工業及民用建筑工程施工部門攪拌干性混凝土、塑性混凝土、流動性混凝土
施工場所，特別適用于在狹窄的艙底建筑修建、維修，能大大提高工作效率。包裝
屬性Specifications 單位Unit 參數Parameter
實際攪拌量Actual stirring capacity m3 1.2
攪拌筒容量Rotary drum capacity m3 1.4
傾斜角Degree of bias ° 16
轉動速度Rotational speed r/min 0-14
轉動方向Direction of rotation 進料：順時針出料：逆時針
Feed:clockwise output:counter clockwise
攪拌筒葉片Mixing drum blade 兩組螺旋葉片及四組輔助葉片Two sets of spiral blades and four sets of auxiliary blades
混凝土坍落度Slump of concrete mm 70-260
液壓傳動系統Hydraulic Power Transmission System
油泵型號Pump model CBGV-4025
馬達型號Hydraulic motor model BMSS-250
減速機速比Reducer ratio 01：10
供水系統Water Supply
水箱容量/供水形式Tank capacity/ water supply form L 540/自帶式自動訂時自動常通供水機構
540/ automatic timing water supply mechanism with automatic timing
底盤主要性能參數發動機主要性能參數The main performance parameters of the chassis and the main performance parameters of the engine
發動機型號/排量Engine type / displacement L CF4B68G-Z-13B2/CF4C100T-Z-13B2
形式model 直噴式四沖程水冷增壓柴油機
Straight injection type four stroke water cooled supercharged diesel engine
額定功率Rated power kw/r/min 55KW/2400 78KW/2400
樶大扭矩Max torque N.m/r/min 255/1500-1800 380/1500-1800
樶大行駛速度Max running speed km/h 24
樶小轉彎半徑Min steering radius mm 5000
爬坡能力Climbing capacity % 26
輪胎Tire 23.5/70-16
驅動形式Driving way 4×4
整車裝備質量Weight kg 4580
樶大裝載質量Maximum load capacity kg 2800
樶大車輛總質量Whole machinery weight kg 7380
整車外形尺寸（長*寬*高）Overall size(L*W*H) mm 6100*1850*3000
