| 型號 | 長度 | 寬度 | 孔徑 | 板厚 | 最大束線徑 | 承受力 | 包裝 | ||||||
| In. | mm | In. | mm | In. | mm | In. | mm | In. | mm | Lbs. | N | ||
| PLWP1M-C | 4.3 | 109 | .098 | 2.5 | .187 | 4.7 | .093 | 2.4 | .87 | 22 | 18 | 80 | 100 |
| PLWP1M-D | 4.3 | 109 | .098 | 2.5 | .187 | 4.7 | .093 | 2.4 | .87 | 22 | 18 | 80 | 500 |
| PLWP1.5I-C | 6.0 | 152 | .135 | 3.4 | .187 | 4.7 | .093 | 2.4 | 1.25 | 32 | 40 | 178 | 100 |
| PLWP1.5I-D | 6.0 | 152 | .135 | 3.4 | .187 | 4.7 | .093 | 2.4 | 1.25 | 32 | 40 | 178 | 500 |
| PLWP1S-C | 5.2 | 132 | .190 | 4.8 | .250 | 6.4 | .105 | 2.7 | 1.00 | 25 | 50 | 222 | 100 |
| PLWP1S-D | 5.2 | 132 | .190 | 4.8 | .250 | 6.4 | .105 | 2.7 | 1.00 | 25 | 50 | 222 | 500 |
| PLWP1SA-D | 5.1 | 130 | .190 | 4.8 | .187 | 4.7 | .093 | 2.4 | 1.00 | 25 | 50 | 222 | 500 |
| PLWP1SB-D | 5.2 | 132 | .190 | 4.8 | .187 | 4.7 | .157 | 4.0 | 1.00 | 25 | 50 | 222 | 500 |
| PLWP1.5S-D | 6.8 | 173 | .190 | 4.8 | .250 | 6.4 | .105 | 2.7 | 1.50 | 38 | 50 | 222 | 500 |
| PLWP1.5SA-D | 6.7 | 170 | .190 | 4.8 | .187 | 4.7 | .093 | 2.4 | 1.50 | 38 | 50 | 222 | 500 |
| PLWP2S-C | 7.8 | 198 | .190 | 4.8 | .250 | 6.4 | .105 | 2.7 | 1.75 | 45 | 50 | 222 | 100 |
| PLWP2S-D | 7.8 | 198 | .190 | 4.8 | .250 | 6.4 | .105 | 2.7 | 1.75 | 45 | 50 | 222 | 500 |
| PLWP2SA-D | 7.7 | 196 | .190 | 4.8 | .187 | 4.7 | .093 | 2.4 | 1.75 | 45 | 50 | 222 | 500 |
| PLWP2SB-D | 7.8 | 198 | .190 | 4.8 | .187 | 4.7 | .157 | 4.0 | 1.75 | 45 | 50 | 222 | 500 |
| PLWP2H-TL | 8.9 | 226 | .300 | 7.6 | .266 | 6.8 | .105 | 2.7 | 2.00 | 51 | 120 | 534 | 250 |
| PLWP3H-TL | 12.0 | 305 | .300 | 7.6 | .266 | 6.8 | .105 | 2.7 | 3.00 | 76 | 120 | 534 | 500 |
?
