PANDUIT重型耐候型尼龍線纜扎帶
PLT4H-TLO,PLT2345H-TLO/CO
產品介紹：
|
產品型號 |
長度 |
寬度 |
最大束線徑 |
承受力 |
包裝 |
||||
|
In. |
mm |
In. |
mm |
In. |
mm |
Lbs. |
N |
||
|
PLT2H-L0 |
8.1 |
206 |
.300 |
7.6 |
2.00 |
51 |
120 |
534 |
50 |
|
PLT2H-TL0 |
8.1 |
206 |
.300 |
7.6 |
2.00 |
51 |
120 |
534 |
250 |
|
PLT2.5H-L0 |
9.8 |
251 |
.300 |
7.6 |
2.50 |
64 |
120 |
534 |
50 |
|
PLT2.5H-TL0 |
9.8 |
251 |
.300 |
7.6 |
2.50 |
64 |
120 |
534 |
250 |
|
PLT3H-L0 |
11.4 |
290 |
.300 |
7.6 |
3.00 |
76 |
120 |
534 |
50 |
|
PLT3H-TL0 |
11.4 |
290 |
.300 |
7.6 |
3.00 |
76 |
120 |
534 |
250 |
|
PLT4H-L0 |
14.5 |
368 |
.300 |
7.6 |
4.00 |
102 |
120 |
534 |
50 |
|
PLT4H-C0 |
14.5 |
368 |
.300 |
7.6 |
4.00 |
102 |
120 |
534 |
100 |
|
PLT4H-TL0 |
14.5 |
368 |
.300 |
7.6 |
4.00 |
102 |
120 |
534 |
250 |
|
PLT6LH-L0 |
21.9 |
556 |
.300 |
7.6 |
6.00 |
152 |
120 |
534 |
50 |
|
PLT6LH-C0 |
21.9 |
556 |
.300 |
7.6 |
6.00 |
152 |
120 |
534 |
100 |
|
PLT7LH-L0 |
24.7 |
627 |
.300 |
7.6 |
7.00 |
178 |
120 |
534 |
50 |
|
PLT7LH-C0 |
24.7 |
627 |
.300 |
7.6 |
7.00 |
178 |
120 |
534 |
100 |
|
PLT8LH-L0 |
27.6 |
701 |
.300 |
7.6 |
8.00 |
203 |
120 |
534 |
50 |
|
PLT8LH-C0 |
27.6 |
701 |
.300 |
7.6 |
8.00 |
203 |
120 |
534 |
100 |
|
PLT9LH-L0 |
30.5 |
775 |
.300 |
7.6 |
9.00 |
229 |
120 |
534 |
50 |
|
PLT9LH-C0 |
30.5 |
775 |
.300 |
7.6 |
9.00 |
229 |
120 |
534 |
100 |
|
PLT5H-L0 |
17.7 |
450 |
.350 |
8.9 |
5.00 |
127 |
175 |
778 |
50 |
|
PLT5H-C0 |
17.7 |
450 |
.350 |
8.9 |
5.00 |
127 |
175 |
778 |
100 |
|
PLT6H-L0 |
20.9 |
530 |
.350 |
8.9 |
6.00 |
152 |
175 |
778 |
50 |
|
PLT6H-C0 |
20.9 |
530 |
.350 |
8.9 |
6.00 |
152 |
175 |
778 |
100 |
|
PLT8H-L0 |
30.6 |
779 |
.350 |
8.9 |
9.00 |
229 |
175 |
778 |
50 |
|
PLT8H-C0 |
30.6 |
779 |
.350 |
8.9 |
9.00 |
229 |
175 |
778 |
100 |
?
