履帶尺寸Track size |
2800*2200mm |
|
裝車尺寸Loading size |
3500*2200*3200mm |
|
履帶板寬Track shoe width |
400mm |
|
鉆孔直徑Borehole diameter |
50-400mm |
|
鉆孔深度Drilling depth |
一桿3m |
|
鉆桿轉速Drill pipe speed |
90r/min |
|
爬坡度Gradient |
30° |
|
動力頭Power head |
22kw |
|
油泵電機Oil pump motor |
15kw |
|
油泵Oil pump |
兩聯Two couplets |
|
油泵型號Oil pump model |
CBG1-F040/040 |
|
油泵轉速Oil pump speed |
2000-2400L/min |
|
油泵壓力Oil pump pressure |
30Mpa |
|
油泵扭矩Oil pump torque |
3000N |
|
發電機組Generator Set |
50kw（特斯拉） |
|
操作方式Operation mode |
液壓hydraulic pressure |
|
液壓油散熱器Hydraulic oil radiator |
強風a fierce wind |
|
燃油箱、液壓油箱Fuel tank, hydraulic tank |
各一個One each |
|
整車重量Vehicle weight |
6T |
|
桅桿mast |
左右、上下可調Left and right, up and down adjustable |
?
